Specification |
|
|
Model: |
20100140 |
|
Battery Type: |
Lifepo4 |
|
Nominal Capacity: |
30Ah |
|
Nominal Voltage: |
3.2v |
|
Battery Dimension: |
20x110x140mm |
|
Battery Weight: |
About 0.65kg |
|
Internal Resistance: |
less than 2 mohms |
|
Cycle life: |
More than 2000 times, DOD at 80% |
|
Combination: |
Can be 4s 8s 12s 16s , etc |
|
Input Charging Voltage |
3.65v/cell |
|
Input Charging Current |
Standard 20A, fast 40A |
|
Continuous Discharging Current |
100Amps |
|
Max Current Discharge |
300Amps |
|
Discharge cut-off Voltage |
2.5v/cell |
|
Charging Temperature: |
0~45Centigrade |
|
Discharging temperature: |
-20~60Centigrade |
|
Storage temperature: |
-20~45Centigrade |
|
Widely Applications: |
Electric vehicle, Electric Bicycle, Tricycle, scooter, golf trolley, cart, wheelchairs, Medical instrument,Solar supply system,solar panel, energy storage, electric tools, power tools, instruments, LED lighting devices, RC toys, inverter, household appliances and emergent device area, etc. |
LiitoKala Brand battery Features
- High energy density
- Long cycle life
- Wide application
- High discharge rate
- Safety: Excellent abuse tolerance and environmentally friendly
- Life: Excellent calendar and cycle life.
Applications:
- Passenger and commercial plug-in hybrid electric vehicles (PHEVs)
- Passenger and commercial battery electric vehicles (BEVs)
- Solar power storeing ,e-bike , e scooter, golf cart And Others .
- wildly use battery, model aircraft, electric tools,power tools , Golf carts, sightseeing coaches,diy battery pack ,solar energy, inverters and others
